Author Topic: Need suggestions for making strongback  (Read 12677 times)

Offline sparky961

  • Hero Member
  • *****
  • Posts: 844
  • Country: ca
Need suggestions for making strongback
« on: April 07, 2015, 06:16:28 PM »
I have a long-term project on the go and the next step requires that I make a "strongback" roughly 12 feet long, with a width between 1-1/2" to just under 2" and height from 3-1/2" to just under 4".  I can deal with some imperfections over the length, say maybe 1/8" deviation over the length, but my main concern is stability.



The obvious answer is to go and buy a 12' long 2x4 at the local building centre.  Although this may be the right choice, I have reservations because the wood I've purchased in the past is practically still growing and often does all sorts of funky things after a few weeks of drying out at home.  If I were to find a really good straight piece, can the stability be ensured by painting or otherwise sealing it?

My second thought was to build a "box beam".  I can use inherently stable wood like plywood, but with a small table saw how do you ensure all your cuts are straight enough, let alone the assembly?  Working with large panels on my Ryobi BT3000 table saw (no infeed/outfeed table or extension) is very unwieldy.

The third and final option I've considered was a piece of 2 x 4 steel tubing.  Stable?  Hell yes.  Overkill?  totally!  Not to mention difficult to mount other things to it that are made of wood, which I will need to do.

So, my question is what's the best (or even a really good) way to move forward?  This seems to have blocked my progress - ie: paralysis through over analysis.

Offline Joe d

  • Sr. Member
  • ****
  • Posts: 251
  • Country: ca
Re: Need suggestions for making strongback
« Reply #1 on: April 07, 2015, 06:29:23 PM »
Hi Sparky

I would go with the box-beam, screwed and glued.
I would expect that your big box outlet would (for a fee, no doubt) cut your plywood for you.

Joe



Offline Lew_Merrick_PE

  • Hero Member
  • *****
  • Posts: 690
  • Country: us
Re: Need suggestions for making strongback
« Reply #2 on: April 07, 2015, 08:35:01 PM »
There are quite a few rectangular steel tube sections as well as 1.75 X 1.75 X .120 Wall square steel tube sections available.  The 1.75 X 1.75 X .120 Wall tube is 2.7 lb/ft.  Current (as of February) pricing on this in Everett, WA (USA) was $1.15/lb.  My local steel supplier lets me go into the warehouse and cherry pick the pieces I want.

???

Offline mattinker

  • Hero Member
  • *****
  • Posts: 1316
  • Country: fr
Re: Need suggestions for making strongback
« Reply #3 on: April 07, 2015, 09:44:27 PM »
You could build the 2 x4 section using4 pieces of  2 x1. We do this in set building when we need larger sections, by gluing (I would screw them from underneath as well) small sections together, the movement is considerably reduced, the centre of your "strong-back" being made of two 2x1s vertically, caped top and bottom by horizontally placed 2x1s. Four reasonably straight pieces can be persuaded to be very straight this way and they remain so even after drying.

Regards, Matthew

Offline S. Heslop

  • Hero Member
  • *****
  • Posts: 1154
  • Country: gb
  • Newcastle Upon Tyne
Re: Need suggestions for making strongback
« Reply #4 on: April 07, 2015, 09:51:28 PM »
I'm far from an expert with wood, but to my understanding wood that has the growth rings running flat and fairly parallel to the board tends to be less likely to warp. It might be worth going with planed square edge (PSE) wood, i've had good experiences with it myself. Googling for stuff on wood stability will probably get you better information though.

If going with the box beam then it might be worth using a PSE board clamped to the plywood as a fence to run a handheld circular saw along.

Wood is a mysterious thing though and I think alot of the time it comes down to luck. It's worth designing things using wood to be able to tolerate some warping (and seasonal expansion).

Offline S. Heslop

  • Hero Member
  • *****
  • Posts: 1154
  • Country: gb
  • Newcastle Upon Tyne
Re: Need suggestions for making strongback
« Reply #5 on: April 07, 2015, 09:55:46 PM »
You could build the 2 x4 section using4 pieces of  2 x1. We do this in set building when we need larger sections, by gluing (I would screw them from underneath as well) small sections together, the movement is considerably reduced, the centre of your "strong-back" being made of two 2x1s vertically, caped top and bottom by horizontally placed 2x1s. Four reasonably straight pieces can be persuaded to be very straight this way and they remain so even after drying.

Regards, Matthew

That reminds me of a thing i've seen guitar builders do, where they cut a board in half and glue it back together with one side flipped so any warping will hopefully get counteracted by the other half.

t=5m

Offline vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 6463
  • Country: us
  • Republic of Vermont
Re: Need suggestions for making strongback
« Reply #6 on: April 07, 2015, 11:18:50 PM »
2 by 2 x square section steel tube with a couple of 1 by 2 firring strips screwed to it, top and bottom.  They'll take your fasteners from wood additions, and the rig will be lighter and cheaper (by far) than 2x4 rectangular tube. Since you said "under" 2, you could also do that with 1-3/4" tube if available locally. That would actually fit 2" firring strips better, unless you ripped out true 2" strips yourself.

What are you making Sparky? A kayak?
I love it when a Plan B comes together!
Steve
https://www.youtube.com/watch?v=4sDubB0-REg

Offline sparky961

  • Hero Member
  • *****
  • Posts: 844
  • Country: ca
Re: Need suggestions for making strongback
« Reply #7 on: April 07, 2015, 11:30:52 PM »
Thanks to all for your suggestions.  I think what I really needed though was a swift kick in the arse to get me off my chair and into the shop.

My worries over how accurate I could build it using tools and materials on hand were, alas, rather silly.  I ended up using some leftover plywood pieces to build a box beam.  Being already cut down to about 20 x 60" they were easier to manage than a full sheet.  Still a handful on the saw, and if they needed to be perfect this wouldn't have been the way.  I discovered that my wood glue was all dried up, so I skipped the gluing.  In hindsight, I do think this would have added appreciable rigidity to the assembly, but again - I'm calling it adequate.  I'm pretty sure that any change in moisture content of the plywood won't cause significant enough stresses to cause warping, bowing, etc.

Future project posting to follow..... sometime.

Offline sparky961

  • Hero Member
  • *****
  • Posts: 844
  • Country: ca
Re: Need suggestions for making strongback
« Reply #8 on: April 07, 2015, 11:36:35 PM »
2 by 2 x square section steel tube with a couple of 1 by 2 firring strips screwed to it, top and bottom.  They'll take your fasteners from wood additions, and the rig will be lighter and cheaper (by far) than 2x4 rectangular tube. Since you said "under" 2, you could also do that with 1-3/4" tube if available locally. That would actually fit 2" firring strips better, unless you ripped out true 2" strips yourself.

What are you making Sparky? A kayak?

I like your idea about using a piece of steel with furring strips on it.  It would be much more rigid than what I have now, but what I've put together seems to be alright for now.

You got your post in just as I was typing mine up, but the last picture was hinting at the application for the strongback. :)

Slow and steady....

Offline Joe d

  • Sr. Member
  • ****
  • Posts: 251
  • Country: ca
Re: Need suggestions for making strongback
« Reply #9 on: April 08, 2015, 07:34:40 AM »
Do we see a kayak coming to life?

Keep posting!

Joe

Offline vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 6463
  • Country: us
  • Republic of Vermont
Re: Need suggestions for making strongback
« Reply #10 on: April 08, 2015, 08:33:45 AM »
Looks like a nice hull, Sparky. You've got a slight warp to the left. Make your mould notches wider than the strongback. Run a snapped chalk centerline down the strongback and set the centerline of the moulds on that to correct.
I love it when a Plan B comes together!
Steve
https://www.youtube.com/watch?v=4sDubB0-REg

Offline sparky961

  • Hero Member
  • *****
  • Posts: 844
  • Country: ca
Re: Need suggestions for making strongback
« Reply #11 on: April 08, 2015, 04:18:16 PM »
Indeed... sounds like you have some experience. I still need to make some stands, then carefully line everything up. Once the first strip or two is on there, nothing should move.

Offline vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 6463
  • Country: us
  • Republic of Vermont
Re: Need suggestions for making strongback
« Reply #12 on: April 10, 2015, 11:22:38 AM »
A little Sparky...me in my shop in the 70's:

I love it when a Plan B comes together!
Steve
https://www.youtube.com/watch?v=4sDubB0-REg

Offline Manxmodder

  • Hero Member
  • *****
  • Posts: 739
  • Country: gb
Re: Need suggestions for making strongback
« Reply #13 on: April 10, 2015, 03:27:29 PM »
I take it that big black woolen hats were very trendy for boat builders in the 70's   :lol: :lol:...OZ.
Helixes aren't always downward spirals,sometimes they're screwed up

Offline sparky961

  • Hero Member
  • *****
  • Posts: 844
  • Country: ca
Re: Need suggestions for making strongback
« Reply #14 on: April 11, 2015, 09:07:30 PM »
What are you working on in the picture? It looks like the two boats in the background are pretty much done.

Offline vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 6463
  • Country: us
  • Republic of Vermont
Re: Need suggestions for making strongback
« Reply #15 on: April 12, 2015, 12:23:22 AM »
Sparky I don't remember!  37 years ago.....  :loco:
I love it when a Plan B comes together!
Steve
https://www.youtube.com/watch?v=4sDubB0-REg

Offline awemawson

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 8966
  • Country: gb
  • East Sussex, UK
Re: Need suggestions for making strongback
« Reply #16 on: April 12, 2015, 02:51:24 AM »
Sparky I don't remember!  37 years ago.....  :loco:

I do so wish that I could make claims like that  :lol:
