Home brew boring facing and radiusing head (video)
« on: January 27, 2017, 06:03:24 PM »
I think you will appreciate this homebrew boring facing head,

The video is in Italian (i think!) but if really needs no verbal explanation:

https://www.youtube.com/watch?v=JHk9tukD7qE

Bill
Bill

Offline millwright

  • Full Member
  • ***
  • Posts: 229
  • Country: gb
  • Leeds West Yorshire
Re: Home brew boring facing and radiusing head (video)
« Reply #1 on: January 27, 2017, 06:38:12 PM »
A nice find Bill, think i you would really need to have a lot of use it to decide to make one.  I would  keep forgetting how to set it up. well made tool and a good video.
John

Offline BillTodd

  • Hero Member
  • *****
  • Posts: 779
  • Country: 00
  • Colchester Essex (where the lathes were made)
Re: Home brew boring facing and radiusing head (video)
« Reply #2 on: January 27, 2017, 06:55:29 PM »
I may have to revise my orbiting lathe tool
Bill

Offline Pete.

  • Hero Member
  • *****
  • Posts: 794
  • Country: gb
Re: Home brew boring facing and radiusing head (video)
« Reply #3 on: January 27, 2017, 07:24:56 PM »
Awesome home-made tool but I'd be disappointed with the finish on that radius. I love the ingenuity of the fine-feed though I can't figure out how they got one tooth different on two gears with the same PCD.

Offline BillTodd

  • Hero Member
  • *****
  • Posts: 779
  • Country: 00
  • Colchester Essex (where the lathes were made)
Re: Home brew boring facing and radiusing head (video)
« Reply #4 on: January 27, 2017, 08:11:51 PM »
The finish might have been better with a slower rpm (less vibration) and hss tooling.

Cutting  a gear with an extra tooth is not too difficult, just adjust addenum slightly to get the smaller pcd ( i made a 61t gear to replace a 60t for metric threads this way)

Bill
Bill

Online PekkaNF

  • Hero Member
  • *****
  • Posts: 1804
  • Country: fi
Re: Home brew boring facing and radiusing head (video)
« Reply #5 on: January 28, 2017, 02:32:45 AM »
That guy is not affraid of small parts. The whole thing looks very inricate.

I wonder how much time went on designing it and was it first designed on CAD or drafted on paper and then evolved up from certain design planes and set points.

Pekka

Offline BillTodd

  • Hero Member
  • *****
  • Posts: 779
  • Country: 00
  • Colchester Essex (where the lathes were made)
Re: Home brew boring facing and radiusing head (video)
« Reply #6 on: January 28, 2017, 04:24:17 AM »
The basic taper head is based on a head by the Tree company. The radius part is, I believe his own. There's a brief flash of cad in the video so I guess he developed it in cad.

bill
Bill

Offline mattinker

  • Hero Member
  • *****
  • Posts: 1028
  • Country: fr
Re: Home brew boring facing and radiusing head (video)
« Reply #7 on: January 28, 2017, 12:04:28 PM »
It's definately in Italien!

Regards, Matthew

Offline Noitoen

  • Full Member
  • ***
  • Posts: 126
  • Country: pt
Re: Home brew boring facing and radiusing head (video)
« Reply #8 on: January 29, 2017, 04:53:38 AM »
It's definately in Italien!

Regards, Matthew

You say It "alien"? :thumbup:

Offline mattinker

  • Hero Member
  • *****
  • Posts: 1028
  • Country: fr
Re: Home brew boring facing and radiusing head (video)
« Reply #9 on: January 29, 2017, 05:44:20 AM »


You say It "alien"? :thumbup:
[/quote]
As a dyslexic bilingual, I am entitled to get my spelling mixed up between the two languages I speak! Smart arse!!

Regards, Matthew

Offline ddmckee54

  • Jr. Member
  • **
  • Posts: 36
  • Country: 00
Re: Home brew boring facing and radiusing head (video)
« Reply #10 on: February 15, 2017, 01:47:48 PM »
Personally, I think it's a conspiracy.  Think about it, most of us have been spelling these words correctly for years if not decades, then along come these PC's and Smart-phones and suddenly we can't spell anymore?  It's not us that are dyslexic, it's the keyboards.  The computers are in on it too and probably spell-checker also.  Why else would we put a word in a sentence when it makes no sense for that word to be there, just because it's spelled correctly?   They're out to get us I tell you.

Tongue firmly in cheek,
Don
Too many irons, not enough fire.

Offline mattinker

  • Hero Member
  • *****
  • Posts: 1028
  • Country: fr
Re: Home brew boring facing and radiusing head (video)
« Reply #11 on: February 15, 2017, 04:22:21 PM »
Personally, I think it's a conspiracy.  Think about it, most of us have been spelling these words correctly for years if not decades, then along come these PC's and Smart-phones and suddenly we can't spell anymore?  It's not us that are dyslexic, it's the keyboards.  The computers are in on it too and probably spell-checker also.  Why else would we put a word in a sentence when it makes no sense for that word to be there, just because it's spelled correctly?   They're out to get us I tell you.

Tongue firmly in cheek,
Don
I don't go along with your conspiracy idea! If my spell check is set to French, (it's usually in the language I'm not writing) then it won't pick up my spelling in the wrong language.

All the best, Matthew

Offline tom osselton

  • Hero Member
  • *****
  • Posts: 844
  • Country: ca
Re: Home brew boring facing and radiusing head (video)
« Reply #12 on: February 15, 2017, 09:29:15 PM »
I'm going with spellchecker! But I have to say some words just look wrong!

Offline Noitoen

  • Full Member
  • ***
  • Posts: 126
  • Country: pt
Re: Home brew boring facing and radiusing head (video)
« Reply #13 on: February 16, 2017, 10:17:48 AM »
When I said It "alien" before, I did not intend to create a discussion. Just made a joke about it because to me, such complicated machining is out of this world, for a hobby shop like mine anyway. Did not want to offend anyone.

Offline S. Heslop

  • Hero Member
  • *****
  • Posts: 930
  • Country: gb
  • Newcastle Upon Tyne
Re: Home brew boring facing and radiusing head (video)
« Reply #14 on: February 16, 2017, 07:04:07 PM »
That's real beautiful. With the complexity of it I was surprised when he cut to one of those bf-20 mills, I was really expecting something alot fancier. Must take some balls, or calluses, to grab onto that knurled section to advance it.
