First project
« on: January 02, 2014, 12:29:57 PM »
Hi   :wave:

After completing my garage conversion over the past year, making some mods to my machines & making stuff to make stuff with, as one does  :dremel: I have finally completed my first project, a simple oscillating engine (double acting) from plans off the internet, original design (1998) by Erik - Jan Stroetinga of the Netherlands. I spent the last couple of days pottering (apart from the New Years eve/day) tweaking a tight spot out of it & now have it running nicely on 8 -10 psi compressed air.

Hopefully the pics attached turn out, showing some of the construction stages & a video of the final running.

George.
