Author Topic: Electronic Leadscrew for the New Lathe  (Read 49844 times)

Offline PekkaNF

  • Hero Member
  • *****
  • Posts: 2020
  • Country: fi
Re: Electronic Leadscrew?
« Reply #125 on: April 14, 2015, 02:37:28 AM »
Aah Forth...When I was a school this was cutting edge. Every processor of it:
http://www.cpushack.com/2013/02/21/charles-moore-forth-stack-processors/

I remember one (least some part of) Norvegian team that was trying to make FORTH-processor for graphics application, bit slices were driven out of everything else than esoteric radar and such signal cruching. And finally out of that too with when signal processors started to appear. With PC:s I lost all interest on computers. Just too many layers of junk.

One more word: Harris. Never used one of those, but some later processors were very much influenced on those designs and ideas.
http://en.wikipedia.org/wiki/RTX2010

Pekka


Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew?
« Reply #126 on: June 28, 2018, 04:58:44 PM »
Guess I better resurrect this ancient thread and try to refresh my memory on what I'd done, if I'm going to use this. 3 years, sheesh!
I love it when a Plan B comes together!
Steve
www.sredmond.com

Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew for the New Lathe
« Reply #127 on: June 29, 2018, 09:39:27 PM »
Okay looking back at he old spreadsheet I see I kind of lucked out on the new lathe. I just this week made a set of pulleys for it and I coincidentally gave them an exact 5 to 1 ratio. I did that at the time mainly because 18T and 90T were good do-able numbers for indexing on my old spin collet, and I lack a dividing head. And because 5 to 1 was in the range of a good reduction ratio for the specs of the treadmill motor I had. To have both of those things work out to exactly 5 to 1 was true dumb luck for me.

Why? Because I hadn't looked at this old electronic lead screw thread. And looking at it now I'm reminded that 5 to 1 is THE absolutely ideal ratio to make this work. Because what it means is that I can attach the 600 line encoder I already have directly to the DC motor and that gives me 3000 lines per rotation at the spindle. The DC motor has an extension shaft on the back end, for very easy attachment.

Looking at the lead screw, the ratio of the stepper motor and lead screw will be 1.5 to 1, that means (with a 200 step motor) the 300 steps per lead screw rotation on a 10 TPI screw yields 3000 steps per inch, super-convenient for the 3000 pulse per turn signal from the spindle.

And that means that simple integer division by the intended TPI will yield the proper pulse rate for the stepper to produce that TPI. Divide encoder pulses by 4, you get  a 4 TPI screw. Divide by 28, you get a 28 TPI screw. etc.

This doesn't even require an Arduino to accomplish. It can be done with perhaps two discreet IC's. Maybe something in the 74LS161 series chained ( I have some). I think that's going to be my approach. If that doesn't work I can always fall back on the programmed Arduino I had already developed 3 years ago in  this thread. But even an SBC is overkill, oversized, and slow and complicated by comparison.

Actually even one modern IC might work -- I don't know what's available these days. Basically I need a divide by N circuit with a max divisor of say 56 (for 56 TPI, or fine feed).
« Last Edit: June 29, 2018, 10:43:15 PM by vtsteam »
I love it when a Plan B comes together!
Steve
www.sredmond.com

Offline awemawson

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 6191
  • Country: gb
  • East Sussex, UK
Re: Electronic Leadscrew for the New Lathe
« Reply #128 on: June 30, 2018, 02:37:16 AM »
Sometimes the toast falls butter side up  :thumbup:
Andrew Mawson
East Sussex

Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew for the New Lathe
« Reply #129 on: June 30, 2018, 07:44:32 AM »
Glad I didn't own a dividing head!

I do need to read my own plan A before embarking on B sometimes.
I love it when a Plan B comes together!
Steve
www.sredmond.com

Offline rowbare

  • Jr. Member
  • **
  • Posts: 36
Re: Electronic Leadscrew for the New Lathe
« Reply #130 on: July 03, 2018, 03:16:43 PM »
And that means that simple integer division by the intended TPI will yield the proper pulse rate for the stepper to produce that TPI. Divide encoder pulses by 4, you get  a 4 TPI screw. Divide by 28, you get a 28 TPI screw. etc.

So what happens to the left over pulses?  3000/28 = 107 r 4

bob

Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew for the New Lathe
« Reply #131 on: July 03, 2018, 03:27:01 PM »
Well, rowbare, I know it's a little difficult to visualize at first, but think about it, and I think you'll get it...they just carry, as long as the thread continues. If you were doing only one turn, yes you'd have a remainder at the end of that turn, but this is a continuous process. In other words, the pulses don't have to line up with the end of each turn. It's just two different frequencies superimposed -- the spindle rotations, and the stepper pulses. Does that make sense?
I love it when a Plan B comes together!
Steve
www.sredmond.com

Offline rowbare

  • Jr. Member
  • **
  • Posts: 36
Re: Electronic Leadscrew for the New Lathe
« Reply #132 on: July 04, 2018, 03:36:08 PM »
If you look at it as superimposed frequencies, there has to be a harmonic relationship between them.

Given a 32 tpi thread (32 shows a bigger error than 28) and 3000 ppr, if the cutter has not moved exactly 1/32 of an inch after 3000 pulses, the thread pitch is off.

3000/32 = 93.75, so a divide by n will provide 93 pulses to the stepper per revolution. After 32 revolutions, the stepper will have gotten 32 * 93 = 2976 pulses and will have moved 0.992 inches cutting a 32.25 tpi thread. It isn't a huge error but an error just the same. It is certainly more significant in theory than in practice though...

bob

Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew for the New Lathe
« Reply #133 on: July 04, 2018, 07:23:20 PM »

3000/32 = 93.75, so a divide by n will provide 93 pulses to the stepper per revolution. .

Nope, it will provide 93 pulses, plus the .75 remainder as a "virtual" timing interval, because the spindle won't have to travel more that 1/4 of its normal inter-pulse distance before sending the next pulse, #94 to the stepper. The encoder has already moved that .75 amount.

See, the encoder doesn't reset once it gets to 93 which is what you're imagining. It's moved past that point just short of the next pulse position. The stepper just sees a continuous regular stream of pulses from the encoder. And those are timed exactly right.

Get it?

The only error is the fineness of resolution of the stepper. But there is no cumulative error from remaindering.

With a perfect leadscrew and a 3000 ppi stepper ratio the tolerance is a flat .00033" at any point along the full travel of the lathe.

I love it when a Plan B comes together!
Steve
www.sredmond.com

Offline beeshed

  • Jr. Member
  • **
  • Posts: 15
Re: Electronic Leadscrew for the New Lathe
« Reply #134 on: July 10, 2018, 06:07:59 PM »
How do you do metric? Since a Norton box is so easy the big value from an ELS is mixing imperial and metric. I think this is where a programmable device is an advantage.

Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew for the New Lathe
« Reply #135 on: July 10, 2018, 10:59:20 PM »
I'm not doing metric.

If you want metric it could be done the same way, but naturally you'd probably want a metric leadscrew anyway, and then you'd work the pulley and encoder ratios the same way but favoring your measurement flavor.

If you want both yeah you could go the microprocessor route. Been there done that earlier in the thread.

If I thought about it hard, I bet I could do it simply with IC's as well. 8 bits (two ls161s) gets you divisors up to 255. And 254 is an interesting number for system conversions. But I don't want to think hard about it right now.
I love it when a Plan B comes together!
Steve
www.sredmond.com

Offline assink

  • Newbie
  • *
  • Posts: 3
Re: Electronic Leadscrew for the New Lathe
« Reply #136 on: July 11, 2018, 06:25:13 AM »
There is actually a german version that works, and seems popular in germany.
https://www.rocketronics.de/els/?v=796834e7a283
Just use google translate  :D
It's also able to do tapers and radius,


Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew for the New Lathe
« Reply #137 on: July 11, 2018, 06:32:57 AM »
Yup, I know, mentioned earlier This thread has long since evolved into making one, though.

Ysee, if  project fora like this one just carried links to manufacturer's web pages, there wouldn't be any interesting projects in them, yes?

 :proj:

 :dremel:  :dremel: :dremel: :dremel: :dremel: :dremel: :dremel: :dremel: :dremel: :dremel:




« Last Edit: July 11, 2018, 07:24:30 AM by vtsteam »
I love it when a Plan B comes together!
Steve
www.sredmond.com

Offline assink

  • Newbie
  • *
  • Posts: 3
Re: Electronic Leadscrew for the New Lathe
« Reply #138 on: July 11, 2018, 07:59:16 AM »
I meant it just for inspiration, have also a link to the full forum page talking about it's working and development. It's rather interesting, but you have to know german or use translate.

Online vtsteam

  • Global Moderator
  • Hero Member
  • *****
  • Posts: 5312
  • Country: us
  • Republic of Vermont
    • www. sredmond.com
Re: Electronic Leadscrew for the New Lathe
« Reply #139 on: July 11, 2018, 09:52:51 AM »
 Fair enough assink. But I should explain what I love - I guess you'd call it elegance in conservation of resources. So I'm real happy with ditching the microprocessor-display-multifunction approach and thinking through a pennies on the dollar four component control solution that will cut any integer thread up to 255 tpi with no cumulative error. I think of that as my kind of fun. And that's what drives me to make my kinds of things and post them on this very unique forum. :dremel:   :beer:
